Hand Sanitizer 4 Head Gravity Bottle Filler 1000 - 5000bottles/Hour

Basic Information
Place of Origin: GUANGZHOU CHINA
Brand Name: TZ
Certification: CE
Model Number: A1
Minimum Order Quantity: 1 PC
Price: Negotiable
Packaging Details: wooden standard packing
Delivery Time: 7-30 work days.
Payment Terms: L/C, D/A, D/P, T/T
Suitable For Bottle Type: According To Samples Provided By Customers Number Of Filling Heads: 2,4,6,8...20head
Filling Capacity: 30ml 50ml 100ml Filling Accuracy:: ±1ml
Production Speed: 1000~5000 Bottles/hour Conveyor Belt: 2mm Wide POM Chain Belt, Height Above Ground 750mm±25mm
Air Pressure: 0.6~0.8MPa Program Control: PLC + Touch Screen Man-machine Interface
High Light:

4 head gravity bottle filler

,

5000bottles/Hour gravity bottle filling machine

,

Hand Sanitizer gravity bottle filler

Hand Sanitizer Gravity Filling Machine 1000 - 5000 Bottles / Hour​



The hand sanitizer filling production line is mainly for filling and packaging machinery lines customized for hand sanitizer, hand gel, shampoo, shower gel, etc.



The main mechanical components are: Gravity filling machine



technical parameter:


1. Suitable for bottle type: according to samples provided by customers
2. Number of filling heads: 2,4,6,8...20head
3. Filling capacity: 30ml 50ml 100ml
4. Filling accuracy: ±1ml
5. Filling form: self-flow quantitative multi-head filling
6. Production speed: 1000~5000 bottles/hour
7. Conveyor belt: 82mm wide POM chain belt, height above ground 750mm±25mm
8. Conveyor motor: frequency conversion motor
9. Machine power: about 3KW/220V, three-phase five-wire
10. Program control: PLC + touch screen man-machine interface
11. The material of the filling frame is stainless steel
12. Filling nozzles and other materials in contact with materials: 304 stainless steel, plastic parts
13. Protection device: alarm for lack of material and shutdown
14. Air pressure: 0.6~0.8MPa



Belt clamp rotary capping machine

technical parameter:


1. Lid sorting method: manual lid sorting
2. Suitable for bottle specifications: according to the model provided by the customer
3. Lower cover form: manual lower cover
4. The form of screw cap: belt clip screw cap
5. Speed: 1000~5000 bottles/hour
6. Material: stainless steel frame
7. Program control: frequency converter speed regulation
8. The conveyor belt uses 82mm wide POM chains, and the conveyor belt surface is 750±25mm high from the ground.
9. The conveying motor adopts frequency conversion drive motor with a speed of 0~10 meters/minute.
10. Machine power: about 1.2KW
11. Air pressure: 0.6-0.8MPa


Vertical round bottle positioning labeling machine

technical parameter;


1. Applicable bottle range: provide samples according to customers;
2. Applicable label range: provide samples according to customers;
3. Production capacity: 1000~5000 bottles/hour
4. Labeling accuracy: ±1mm
5. The conveyor belt uses 82mm wide POM chains, and the conveyor belt surface is 750±25mm high from the ground.
6. Conveying motor: 140W frequency conversion motor
7.Power supply: 220V/50HZ single phase;
8. Power: about 0.6KW;
9. Program control: PLC and touch screen man-machine;
10. Applicable paper roll: 76mm inner diameter and 300mm outer diameter.
