3000 Bottles/H Explosion Proof Electric Alcohol Filling Machine

 Alcohol filling machine equipment line with explosion-proof

advantage:

      The automatic explosion-proof alcohol filling machine is a professional alcohol packaging machine, which can treat various alcohols such as electronic alcohol, medical alcohol, perfume alcohol, edible alcohol, corn alcohol and other liquid flammable products.

The combination of rich production experience and advanced production equipment has cultivated our high-speed and superb shipping speed.

1.Suitable for bottle type: according to the sample provided by the customer

2.Number of filling heads: 4~10nozzle

3.Filling capacity: 100 ~ 1000ml

4.Filling accuracy: 99.5%

5.Filling form: constant pressure and self flow.

6.Production speed: 500 ~3000bottles / hour (based on 1000ml / bottle)

7.Conveyor belt: 82mm wide POM chain belt, 750mm ± 25mm above the ground

8.Conveyor belt motor: frequency control motor

9.Overall power: About 3KW / 380V, three-phase five wire

10.Program control: PLC + touch screen human-machine interface

11.The filling rack is made of stainless steel

12.Materials of filling nozzle and material contact parts: 304 stainless steel

13.Tank capacity: 40 L * 2

14.Feeding pump: 304 stainless steel self-priming pump

15.Protection device: material shortage shutdown alarm

16.Air pressure: Air pressure:

17.Positive pressure explosion-proof measures shall be adopted for exposed motors and other electrical appliances
