| Place of Origin: | Guangzhou China |
|---|---|
| Brand Name: | TengZhuo |
| Certification: | CE |
| Model Number: | TZ |
| Minimum Order Quantity: | 1SET |
| Price: | Negotiated |
| Packaging Details: | wooden cases |
| Delivery Time: | 30 days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Material: | 304 Stainless Steel | Core Components: | Motor, Pressure Vessel, Pump, PLC |
|---|---|---|---|
| Name: | Automatic Lube Oil Filling Machine | Products: | Engine Oil / Lubricant Oil |
| Driven Type: | Pneumatic, Compressed Air, And Electric | Machinery Capacity: | 4000BPH, 8000BPH, 6000BPH, 2000BPH |
| Filling Material: | Oil, Lube Oil | Key Selling Points: | High-accuracy |
| Filling Accuracy: | ±0.5-1.0% | Control System: | PLC+ Touch Screen |
| High Light: | 4000BPH Bottling Cap Packing Machine,PLC Bottle Cap Packing Machine |
||
Engine Oil / Lubricant Oil Bottle Filling Line Bottling Capping Packing Machine Line
viscosity liquid / Brake Oil / Lube Oil Filling Bottling Capping Packing Machine Line
AUTOMATIC Lube/Engine/Car Oil FILLING MACHINE
automatic servo piston filling machine is extremely flexible filler, is capable of filling accurately and rapidly any oil,such as lube oil,engine oil,motor oil,antifreeze and brake fluid.
MAIN FEATURE
304 Stainless steel construction and the oil contact parts.
Controlled by panasonic servo motor
Japan Panasonic servo motor
Schneider touch screen and PLC
Accuracy+0.2% for 1000ML
Use anti-drip filling head to prevent the last drop after filling and with automatic drop collection tray double safety system
similar filling machine such as:
| engine oil packing machine |
| lubricant packaging machine |
| lubricant oil filling machine |
| lube oil filling machine |
| motor oil filling machine |
| high viscosity liquid filling machine |
| lubricant oil packing machine |
| lubricant oil packing machine |
| brake oil filling machine |
| brake fluid filling machine |
| lubricant filling machine |
| engine oil filling machine |
| Name | Engine Oil / Lubricant Oil Bottle Filling Line Bottling Capping Packing Machine Line |
| Filling volume | 300-5000ml |
| Filling Heads | 1—12 |
| Capacity | 2000-3500 bottles/hour |
| Control system | PLC+ Touch screen |
| Precision | ±0.5-1.0% |
| Bottle height | 100-380 mm (adjustable) |
| Voltage | AC220V or AC 380V |
| Power | 2.0-3.5Kw. |
| Pneumatic | 0.35cbm/min, 0.6-0.8Mpa |
| Dimension | L2100*W1050*H2050mm |
| G.W. | 900-1200Kg. |
| Auxilary equipments | Auto bottles feeder, auto capping machine, auto induction sealing machine, auto labelling machine, shrink labelling machine, ink-jet printer, auto carton packing machine,etc. |
No Dead Corner top tank.
1.The top tank is with round or semi round design no dead corner, more easy Cleaning
2.Double jacket hopper optional
3.Mixing system optional
4.CIP system optional
5. 304SS constuction material, 316SS for option
