Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam

Basic Information
Place of Origin: GUANGZHOU ,CHINA
Brand Name: TZ
Minimum Order Quantity: one set
Price: directly factory offer
Packaging Details: export wooden case packing
Delivery Time: 45 work days.
Payment Terms: T/T, Western Union, MoneyGram
Automatic Grade: Fully Automatic Key Selling Points: Easy To Operate
Feature: Effective Filling And Sealing Type: Capping Machine
Speed: 1500-2000 Bottles/hour Material: Stainless Steel Frame
Screw Cap Form: Vacuum Seal Screw Cap Air Pressure: 0.6-0.8MPa
High Light:

Glass Bottle Jar Vacuum Capping Machine

,

2000 Bottles / Hour Vacuum Capping Machine

,

Condiments Vacuum Capping Machine



Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 0



China factory Glass Bottle Jar Vacuum Capping Machine for food sauce jam



The vacuum capping machine is suitable for automatic sealing of special-shaped glass screwing bottles such as condiments, sauces, jams, etc., and has a vacuum function, suitable for the production of various foods such as fruits, beverages, and sauces; the machine has operation Stability, high vacuum, and sealing quality in line with standards. The key components are processed by high-precision equipment, and the machining accuracy is improved to ensure the stability of the entire machine. It is realized that the air in the bottle is sucked out while the cap is screwed, so that the food can be better stored.



technical parameter:
Adapt to bottle cap: 38-82mm (customized according to requirements, can be customized according to customer's bottle)
Adapt to bottle height: 30-180mm (customized according to requirements, can be customized according to the customer's bottle)
Weight: 450kg

Material: Outer body 304# stainless steel.

Cover arrangement method: ladder belt lifting mechanism cover

Suitable bottle specifications: according to the sample provided by the customer

Lower cover form: mechanical lower cover can be added

Screw cap form: vacuum seal screw cap

Speed: 1500-2000 bottles/hour

Material: stainless steel frame

Program control: frequency converter speed regulation

Conveyor belt: 82mm or 114mm wide stainless steel chain belt, speed 0-15m/min, height above ground 750mm±25mm

Power of the whole machine: about 0.6KW

Air pressure: 0.6-0.8MPa



China factory Glass Bottle Jar Vacuum Capping Machine for food sauce jam is suitable for the sealing of the tinplate cap after the food is filled in the glass bottle, and the vacuum is good, which is convenient for the better storage and maintenance of the food.

Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 1Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 2Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 3Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 4Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 5Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 6



Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 7

Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 8

any question, please contact with Cindy freely, 008613794308529,  36226571@qq.com, thanks



Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 9Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 10



Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 11Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 12Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 13Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 14Glass Bottle Jar Vacuum Capping Machine For Food Sauce Jam 15
