Full Automatic Cosmetics Filling Machine Automatic Bottle Filling And Closing Machine Oil Sauce Honey Bottle Filling Mac

Basic Information
Place of Origin: China
Brand Name: Tengzhuo
Certification: CE Own patent
Model Number: WFM001
Minimum Order Quantity: One set
Packaging Details: film pack with wooden case
Delivery Time: 30-40 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100 pcs per month
Product Name: Automatic Filling Machine Usage: Bottle Filling
After-sales Service Provided: Online Support Filling Speed: 10-50 Bottles/minute
Number Of Filling Heads: 4 6 8 10 12 Conveying Speed: 5-15 Meters/minute
Filling Capacity: 100~5000ml (customized According To Customer Requirements) Suitable For: Liquid Oil Sauce
Packing Material: Wood

Automatic servo filling machine adopts servo control filling capacity, touch screen control, accurate accuracy, easy adjustment,

one-button cleaning function, easy disassembly and assembly. The main electrical components are all international brands,

PLC and touch screen human-machine interface, suitable for filling Contains products with various viscosities from liquids to creams,

suitable for various industries such as daily chemicals, medicine, food, pesticides, etc.

Full Automatic Cosmetics Filling Machine Automatic Bottle Filling And Closing Machine Oil Sauce Honey Bottle Filling Mac 0Full Automatic Cosmetics Filling Machine Automatic Bottle Filling And Closing Machine Oil Sauce Honey Bottle Filling Mac 1

Product Name: Automatic Filling Machine
Filling Speed: 10-50 bottles/minute
Filling volume: 30-500 ml, 60-1000 ml, 250-2500 ml, 500-5000 ml
Filling Accuracy: ±1%
Filling Nozzels: 4/6/8/10/12 pcs (Customization)
Working Voltage: As customization
Application: Filling for Bath cream. Shampoo. Detergent. Lotion,Liquid soap, Liquid hand washer, ail polish remover, conditioner,hair care, liquid, low viscosity liquid etc liquid products

Technical Parameters:

Number of filling heads: 4 6 8 10 12 (customized according to customer production requirements)

Filling capacity: 100~5000ml (customized according to customer requirements)

Filling form: servo filling

Theoretical filling speed: 10-50 bottles/minute

Filling accuracy: 1%

Conveying speed: 5-15 meters/minute

Belt width: 82 (mm)

Conveyor belt: 3 meters steel chain plate type

Conveyor belt height from the ground: 800±25 (mm)

Machine power: 5KW/220V AC single phase

Program control: International brand PLC with touch screen human-machine interface

Gas source: 0.5-0.8MPa
