Double Side Semi Automatic Bottle Labeler Flexibly Adjusted Distance

Semi-automatic Round Bottle Label Machine

It is mainly composed of host, paper feeding, paper receiving, bottle positioning and other mechanisms. The bottle is manually placed in the positioning mechanism. After positioning the bottle, press the handle switch, and the label will be automatically attached to the bottle.

Scope of application:

Applicable labels: stickers, electronic supervision codes, barcodes, etc.

Applicable products: Products that require labeling on flat, curved, circumferential, concave, convex, or other surfaces.

Application industry: widely used in food, toys, daily chemicals, electronics, medicine, hardware, plastics, printing and other industries.

Powerful, single-label, double-label labeling function can be switched at will.

The distance of Label Machine can be flexibly adjusted, and the circumferential positioning function can be selected to set the position label on the circumferential surface;

Supports conical bottle labeling, with taper adjustment knob, simple adjustment to meet the taper bottle labeling;

1, Semi-automatic Round Bottle Label Machine quality is good, and it has the dual positioning of product positioning and label rectification.

2, the label has a high degree of overlap between the head and the tail, no wrinkles and no bubbles, and the quality is improved;

3, the adjustment is simple, and the various functions are switched by one button, and the labeling of different product labels is simple and quick to switch, and the efficiency is improved;

4, Safe and hygienic, in line with GMP production requirements, the main materials are stainless steel and high-grade aluminum alloy, which is durable and durable;

5, Stable performance, controlled by PLC+ fiber optic sensor electronic control system, supporting equipment for a long time;

6, Production management is convenient, with labeling count, photoelectric tracking label and other functions, production management is easier.

Semi-automatic Round Bottle Label Machine technical parameters, other special requirements and functions, can be customized

• Applicable label length (mm): 15mm ~ 380mm
• Applicable label width (backing paper width / mm): 10mm ~ 180mm
• Applicable product diameter (for round bottle): φ15mm～φ160 mm
• Applicable standard roll outer diameter (mm): φ240mm
• Applicable standard inner diameter (mm): φ76mm
• Labeling accuracy (mm): ±0.5mm
• Marking speed (m/min): 8m/min
• Labeling speed (pcs/min): 20~40pcs/min
• Weight (kg): about 35kg
• Voltage (V): 220V/50HZ
• Power (W): 200W

Optional features and components:

1 hot coding function;

2 circumferential positioning function;

3 other functions (customized according to customer requirements).
