Eco - Friendly Linear Capping Machine / Bottle Screw Capping Machine

Basic Information
Place of Origin: GUANGZHOU ,CHINA
Brand Name: TZ
Minimum Order Quantity: one set
Price: Negotiable
Packaging Details: wooden standard packing
Delivery Time: 7-55 work days.
Payment Terms: L/C, T/T, Western Union
Application: Beverage, Medical, Chemical Type: Inline Bottle Capping Machine
Driven Type: Electric Feature: Convenient Operation
Warranty: 1 Year Packaging Type: Bottles Packaging Material: Glass, Metal, Plastic Condition: New
High Light:

bottle screw capping machine

,

automatic bottle capping machine

Inline bottle capping machine



Inline bottle capping machine includes a capping machine, a capping track, a bottle clamping transmission mechanism, and a capping wheel transmission mechanism.



The bottle completes the action of lowering, pressing and rubbing during the horizontal movement of the bottle under the action of the clamping belt. It is suitable for the capping of screw caps of round bottles and flat bottles (pots) of various materials.



Advantage of inline bottle capping machine:

  1. The overall structure is simple and easy to adjust.
  2. There is no need to change accessories when changing the bottle type, just adjust the position of individual parts,
  3. During the capping process, no bottle or cap can be achieved.
  4. High capping rate and fast speed,
  5. This equipment uses a photoelectric detection to remove the reverse cover, which improves the supply speed and qualified rate.
  6. At the same time, the air consumption is reduced, which guarantees sanitation and energy saving.

Product parameters

Applicable bottle diameter: 20mm-130mm

Applicable bottle height: 30mm-320mm

Applicable bottle cap: 20mm-100mm, height 10-60mm

Capping speed: ≤3000 bottles / hour

Air source pressure: 0.6-0.8 MPa

Power supply: AC220V, 50Hz
